Upright Microscope BX53

Upright Microscope BX53
Upright Microscope BX53
Product Code : DILM001
Brand Name : DIDAC
Product Description

Description of Upright Microscope BX53

The entire optical path of the BX53 is designed for optimal fluorescence imaging, using UIS2 components that set new standards in precision and clarity. High-quality mirror cube coatings provide excellent transmission and steep cut-offs, while almost all stray light is eliminated from interior surfaces for the best sensitivity and color separation. Other advanced features further facilitate fluorescence microscopy, including a new fly-eye lens system, which delivers homogenous illumination, and automatic magnification and filter cube read-out, which simplifies the repetition of settings. Additionally, the BX53 semi-motorized fluorescence microscope makes highly efficient imaging possible. Automation enables the imaging of large areas in high magnification and also facilitates multicolor fluorescence.

Specification of Upright Microscope BX53

Observation Method

Fluorescence (Blue/Green Excitations)

P

Fluorescence (Ultraviolet Excitations)

P

Differential Interference Contrast

P

Phase Contrast

P

Polarized Light

P

Simple Polarized Light

P

Brightfield

P

Darkfield

P

Illuminator

Transmitted Koehler Illuminator

Halogen Lamp

100 W

Fluorescence Illuminator

Hg Lamp

100 W

Xenon Lamp

75W

Light Guide Illumination

P

Focus

Focusing Mechanism

Stage Focus

P

Intermediate Magnification Changer

Manual Terret

P

Revolving Nosepiece

Motorized

Max. 7 position

Manual

Coded

Max. 7 position

Standard Type

Max. 7 position

Stage

Mechanical

Mechanical Stages with Right-Hand Control

X: 76 mm, Y: 52 mm

Oil Rectangular Stage with Right-Hand Control

X: 76 mm, Y: 52 mm

Plain Stage

U-SP

Rotatable Graduated Stage

Rotation: 360 degrees

Condenser

Motorized

Universal Condenser

Dry: NA0.9/ W.D.1.5 mm, Oil: NA1.4/ W.D.0.63 mm (1.25 X - 100 X)

Manual

Universal Condenser

Dry: NA0.9/ W.D.1.5 mm, Oil: NA1.4/ W.D.0.63 mm (1.25 X - 100 X)

Swing-Out Condenser

NA0.9/ W.D.2 mm (1.25 X - 100 X)

Achromatic/Aplanatic Condenser

NA1.4/ W.D.- (10 X - 100 X)

Ultra Low Condenser

NA0.16/ W.D.- (1.25 X - 4 X)

Darkfield Condenser Dry

NA0.8 - 0.92/ W.D.4.52 mm (10 X - 40 X)

Darkfield Condenser Oil

NA1.2 - 1.4/ W.D.0.5 mm (20 X - 100 X)

Low Magnification Condenser

NA0.75/ W.D.1.55 mm (2 X - 100 X)

Abbe Conenser

NA1.1/ W.D.- (4 X - 100 X)

Phase Contrast Condenser

NA1.1/ W.D.0.7 mm (4 X - 100 X)

Polarizing Condenser

NA0.9/ W.D.- (4 X - 100 X)

Observation Tubes

Widefield (FN 22)

Binocular

P

Tilting Binocular

P

Trinocular

P

Tilting Trinocular

P

Ergonomic Tilting Binocular

P

Tilting, Telescopic, Lifting Binocular

P

Trinocular for Infrared

P

Erected Trinocular

P

Erected Ergonomic Tilting Binocular

P

Super Widefield (FN 26.5)

Trinocular

P

Erect image tilting trinocular

P

Dimensions

274.5 (W) x 614 (D) x 469 (H) mm (Epifluorescence Configuration)

Weight

21 kg (Epifluorescence Configuration)

Operating Environment

Indoor Use

Ambient Temperature

5 - 40 ºC (41 - 104 ºF)

Maximum Relative Humidity

80 % for temperatures up to 31 ºC (88 ºF), decreasing linearly through 70 % at 34 ºC (93 ºF), 60 % at 37 ºC (99 ºF), to 50 % relative humidity at 40 ºC (104 ºF)

Supply Voltage Fluctuations

±10 %
