Product Code : DIBI052
Brand Name : DIDAC
Product Description

Thermo Lab

  • Quadrothermal shaking water bath with four separate, independently adjustable basins.
  • Microprocessor controlled temperature control.
  • Excellent temperature stability: ± 0.1 ° C at 50 ° C.
  • Optimal temperature distribution throughout the working area.
  • Temperature display and setting digital via LED display, in increments of 0.1 ° C.
  • Folio keyboard with distinctive symbols.
  • Electronic function monitoring of the temperature controller. In the event of a fault, the cause of the fault is indicated in the display.
  • Two independent over-temperature protection devices.
  • Maintenance-free and low-wear shaker, electronically controlled and infinitely variable shaking movement, gentle start.
  • Height-adjustable sample holders.
  • Four double-walled, thermally insulated, inward curved lids - no dripping back of condensate into the vessels.
  • Interior and stainless steel shaking inserts
  • Corrosion-resistant outer housing made of electrolytically galvanized steel sheet, powder coated.
  • Drain cock at the back.

Thermo Lab

Temperature range

Approx. 5 ° C above room temperature to 99.9 ° C

Movement type

Back and forth, switchable

Shaking frequency

Of 2 - 50 rpm

Shaking amplitude

22 mm

Usable bath height

80 mm

Sample holder

Height adjustable, 32 mm

Measurements of specimen holder

128 x 128 mm

Working space dimensions (W x D x H)

175 x 175 x 100 mm, per basin

Outside dimensions (W x D x H)

625 x 556 x 270 mm

Electrical connection

230 V / 50 ... 60 Hz / 1.3 kW

Net / gross weight

28.0 / 36.0 kg
